EG4 Hybrid AC/DC Mini Split | 12000 BTU | Energy Star, AHRI
The Do-It-Yourself EG4 12K Mini-Split is a highly efficient, 12000 BTU air conditioning system that provides great cooling and heating performance in small to medium-sized rooms. Featuring a new SEER2 rating of 22, this unit offers energy savings as well as cost efficiency without sacrificing cooling/heating power. Its compact size, sleek design, and new Plug-N-Cool technology make this EG4 Mini-Split a Do-It-Yourself project. Plug-C-Cool allows the EG4 Mini-Split to be easily installed, cooling and heating quickly in virtually any living space or workplace.
Included:
- Indoor Head Unit
- Outdoor Unit
- Pre-Charged Lineset & Electrical Wire - 16.4Ft
- LCD Remote Control
- Installation Accessories
New Plug-n-Cool Technology - Easy Do-It-Yourself Installation
Allows for quick and easy connection via the quick-connect self-closing companion valves. Plug-n-cool allows you to install this innovative mini-split system without special tools, equipment, or training. No need to pull a vacuum.
Latest & Greatest Efficiency Rating - New SEER2 Rating: 22
Go above and beyond the norms of other efficient mini-split systems while maintaining maximum performance, safety, and reliability.
- Over 12000BTU of Heating & Cooling Capacity - Heat & Cool up to 650 Square Feet
- Get sophisticated air conditioning medium to large-sized rooms.
- Type: Hybrid – AC/DC Driven
- Rated BTU: 1 Ton / 12000
- Coverage: 650 Square Feet
- SEER2 Rating: 22
- Capacities: 3,000-13,000 BTU/H
- Indoor Unit Sound: (Turbo/5/4/3/2/1 Block) 37/36/35/34/33/32 Db(a)
- Outdoor Unit Sound: (Hi/Med/Lo) 52 Db(a)
- HSPF2: 10.5
- COP: 11.9 BTU/W
- Recommended Solar Input: 1000-1600W (90VDC-380VDC)
- Operating Temperature: (-10℃ to 58 ℃)
- Operation Temperature Indoor (Cooling/Heating): 61-90/32-90 °F
- Operation Temperature Outdoor (Cooling/Heating): 32-131/5-86 °F
- Weight: 49.9 KG / 110.22 Lbs
- Solar Aircon App: Yes
- ENERGY STAR®: Yes
